PICO 8|10 DSP - 18 Volt Mosconi Pico Line 8 Channel Class D 18 Volt Amplifier With Built-In 10 Channel DSP, 4x50W + 4x80W 4 Ohm, Car Audio Amplifier

by Mosconi
Save 17% Save 17%
Original price $1,560.00
Original price $1,560.00 - Original price $1,560.00
Original price $1,560.00
Current price $1,299.99
$1,299.99 - $1,299.99
Current price $1,299.99
🚚 Order within the next 2 hours, 15 minutes for delivery by 06 Oct, 2024.
Availability:
Low stock

PICO 8|10 DSP - 18 Volt

8 Channel Class D Amplifier with Built-In 10 Channel DSP

FEATURES:

  • 18 Volt
  • Ultracompact Multichannel DSP Amplifier

OPTIONAL ACCESSORIES:

  • RTC-2 for Remote Control
  • EXT4RCA (2) for Low Level Input
  • EXT4HLIN for Channel Expansion

SPECIFICATIONS:

  • Power Supply Voltage: 18V
  • Onboard fuse: 1 x 30A
  • Overall efficiency: >80%
  • Power output: 50Wx4 + 80Wx4 (or 45×4 + 210Wx2) RMS on 4Ohm @ 14.4V, BTL connection allowed only on CH 5-6 and CH 9-10 Outputs
  • Analog DSP processed output: 2 x 2Vrms
  • Analog Input: 4x high level + 4x high/low level (EXT4RCA adapter available)
  • Low level + High level input sensitivity range: 2Vrms (LL) – 15Vrms (HL) by default
  • Input impedance >15k Ohm (LL) – 600 Ohm / ~22 Ohm (HL)
  • Low Level Ground Reference: Full Floating/ ~22 Ohm
  • Autosense power-on: Available by High Level, BTL source only
  • Digital input: Optical (Toslink), CARD (MOS standard modules and Extended cards)
  • Onboard DSP: 294.912 Mhz – 64 bit
  • Onboard ADC: 96kHz/24bit Sample Rate – 107dB S/N ratio
  • Onboard ADC: 96kHz/24bit Sample Rate – 106dB S/N ratio
  • Remote control (optional): RTC
  • Dimensions: 150 x 160 x 46mm / 5.90" x 6.30" x 1.81" inches
  • Weight: 1.05Kg / 2.31 lbs
