45L7R104 KICKER 10" L7R Solo-Baric Square Subwoofer Sub 500W RMS 4 Ohm DVC
by Kicker
Sold out
Original price
$259.99
Original price
$259.99
-
Original price
$259.99
Original price
$259.99
Current price
$239.99
$239.99
-
$239.99
Current price
$239.99
🚚 Order within the next 2 hours, 15 minutes for delivery by 28 Aug, 2025.
Availability:
Out of stock
10" Solo-Baric L7R 4 Ohm
The engineers at KICKER invented the original square sub right here in the heart of America. Designed to give you more bass - yet take up no more air space - than a standard round sub. Welcome to the miraculous world of the L7R!
- Dual four-Ohm Voice Coil
- Wrap Around Gasketing
- Patented Ribbed Corners
- Injection-Molded SoloKon™ Woofer
- 360-Degree Back Bracing
- UniPlate™ Back Plate And Pole Piece
- Bumped Back Plate
- Thick Tinsel Leads
- Large Ceramic Magnet
- Steel Basket With Spoke Design
- Nickel Plated Speaker Terminals
The L7R 10-Inch Subwoofer works best with 500 watts of recommended power in a sealed or ported enclosure. See below for more details.
Specifications
| Thiele/Small Parameters |
| 45L7R104 T/S Parameters |
| Product Dimension Sheet |
| 45L7R10 Dimensions |
| SIZE [in, cm]: |
| 10, 25 |
| IMPEDANCE [Ohms]: |
| 4 DVC |
| Recommended Amplifier Power (watts RMS) |
| 500 |
| Peak Power (watts, per ANSI/CTA-2031-A) |
| 1000 |
| SENSITIVITY [dB 1w/1m]: |
| 85.9 |
| MOUNTING DEPTH [in, cm]: |
| 6-1/8, 15.7 |
| MOUNTING DIAMETER [in, cm]: |
| 9-5/16, 23.7 |
| MIN SEALED BOX VOL [cu. ft, L]: |
| .66, 18.7 |
| MAX SEALED BOX VOL [cu. ft, L]: |
| 1, 28.3 |
| MIN VENTED BOX VOL [cu. ft, L]: |
| 1.25, 35.4 |
| MAX VENTED BOX VOL [cu. ft, L]: |
| 2.25, 63.7 |
| What's in the Box: |
| 1 - 10" Subwoofer, 1 - install manual, 2 - Kicker stickers |
| Warranty |
| When purchased from an Authorized KICKER Dealer or kicker.com, KICKER warrants this product to be free from defects in material and workmanship under normal use for a period of ONE (1) YEARS from date of original purchase. |
