RS-SB12 Alpine R-Series 12" Shallow Subwoofer Sub Single Loaded Down Firing Enclosure 600W RMS 2 Ohm

RS-SB12 Alpine R-Series 12" Shallow Subwoofer Sub Single Loaded Down Firing Enclosure 600W RMS 2 Ohm

by Alpine
🚚 Order within the next 2 hours, 15 minutes for delivery by 23 May, 2024.
Save 25% Save 25%
$850.00
$850.00 - $850.00
$850.00
$639.95
$639.95 - $639.95
$639.95
Availability:
Low stock
Request a quote

RS-SB12

Single 12” R-Series Shallow Preloaded Subwoofer Enclosure



SHALLOW YET POWERFUL

With an ultra-shallow enclosure design and powerful sound output, the R-Series Shallow Preloaded Subwoofer Enclosures give you the best of both worlds in size and sound.

DESIGNED FOR TIGHT SPACES

Now you don’t have to choose between bass and space! Alpine’s R-Series Shallow Preloaded Subwoofer Enclosure measures at a minimal 5.25” deep to deliver a loud and fun sound in most vehicle applications. Rubber “feet” are adjustable in height to accommodate uneven vehicle floors.

EXTREME OUTPUT

Don’t let the size fool you – the enclosures feature the same motor movement (20MM of 1-way excursion) as the full-size R2-Series Subwoofers for extreme output in a shallow woofer design. At the heart of the R-Series Shallow Subwoofers is an oversized 4-inch voice coil that houses the lightweight and powerful neodymium magnet for 600W RMS of power handling.

RELIABLE PERFORMANCE

Integrated cooling fins located in the core of the subwoofer help dissipate the heat generated by the rapid subwoofer movement for enhanced cooling reliability and hours of uninterrupted playtime. The Unique CoolMount™ Dual-panel mount subwoofer motor enhances cooling.

PRECISE BASS CONTROL

Alpine's Gen2 DD-Linear Magnetic Circuit technology, a compact and efficient dual-gap voice coil structure, allows for better control over the motor, resulting in lower distortion and precise bass control. The preloaded enclosures use the subwoofer frame as bracing for a more ridged design and better bass response.

POWERFUL BASS PROJECTION

A lightweight yet rigid aluminum dust cap allows the R-Series Shallow Subwoofer to transition sound quickly with minimal distortion and project the bass off the surface of the speaker for hard-hitting yet smooth bass performance. The included adjustable mounting brackets allow for down-fire mount configuration.

OPTIMAL POWER MATCH

With dual voice coils wired in parallel for a 2 ohm load, the Alpine R-Series 12" Shallow Subwoofer Enclosure is optimized to perform with Alpine's S-A60M and R-A75M mono amplifiers.

Product highlights:

  • sealed enclosure with one 12" subwoofer — can be used as upward- or downward-firing enclosure
  • 3/4" medium-density fiberboard construction covered with carpet
  • 2-ohm total impedance
  • frequency range: 26-200 Hz
  • power handling: 600 watts RMS (1800 watts peak power)
  • sensitivity: 81 dB
  • steel mesh grille included
  • dimensions: 26.63"W x 5.38"H x 17.13"D (without feet)
  • MFR # RS-SB12

What's in the box:

Alpine RS-SB12 owner's manual

  • Subwoofer enclosure loaded with one RS-W12D4 12" subwoofer
  • 8 Rubber feet
  • 4 Plastic spacers
  • Eight M5x15mm screws (installed)
  • Four M5x25mm screws
  • Four M5x45mm screws
  • 4 Flat-washers
  • Installation guide
  • Parts list
  • Warranty information
  • Registration information
  • Important notice
